Specifications :
Part No. | HT-4244-FT-SF |
Frequency | 4200-4400MHz |
Bandwidth | 200MHz |
Inestion Loss | ≤1.0dB@ ≤2.0dB@（-40℃-85℃） |
Ripple | ≤1.0dB |
Return Loss | ≥16 dB |
Rejection | DC-1000MHz≥70dB 1200-1300MHz≥75dB 1300-1500MHz≥90dB 1500-4000MHz≥80dB 4500-5800MHz≥80dB 9000-9300MHz≥90dB 10-12.5GHz≥70dB |
Temperature | -20℃～+60℃ |
Connector Type | SMA-F |
Size | 55X50X15MM |
Color | Black |
Outline Drawing :
