Specification:
Part No. | HT-DP-1721-43F | |
Port | Port1 | Port2 |
Frequency(MHz) | 1710-1880 | 1920-2170 |
Insertion loss(dB) | 0.3typical 0.35max | 0.3typical 0.35max |
Return Loss(dB) | 20 typical 18 min | |
VSWR | ≤1.3 | |
Isolation(dB) | 52 typical 50dB min | |
Intermodulation (dBc) | <-160dBc typical ,< -155 dBc Max (with 2x43 dBm) | |
Impedance (Ω) | 50 Ω | |
DC Pass Current | 3A | |
Input power (W) | 200 | |
Operation temperature | -40 °C to +65 °C | |
Storage temperature | -55 °C to +85 °C | |
Relative humidity | 5% - 95% | |
Lightning Protection | ±5KA 8/20us | |
Application | Indoor or Outdoor(IP67) | |
Connector | 4.3-10 Female | |
Color | Grey | |
Weight(kg) | ≤3.0 | |
Dimension(mm) | 133*118.7*83mm | |
Outline Drawing:
